Observium tries to open munin graphs from the wrong path

Details

    • Bug
    • Resolution: Fixed
    • Major
    • None
    • Professional Edition
    • Web Interface
    • None

    Description

      Hi.

      after updating observium to 23.9.13005 it seems to be the web interface tries to open the munin graphs from the wrong path.

      the rrd's are saved under the hostname but the web interface tries to open it directly from the rrd path.

      E.g.:

      real path: /opt/observium/rrd/10.242.0.9/munin_ping_10.242.0.10_ping.rrd

      web interface tries to open: /opt/observium/rrd/munin_ping_10.242.0.10_ping.rrd

      Error Messages says: No such file or directory.

      How we can fix this issue?



      BR. Torsten

      Attachments

        Activity

          [OBS-4624] Observium tries to open munin graphs from the wrong path

          ok. got answer via discord about this trouble. It is not in the stable branch yet. Thanks a lot.

          twilms Torsten Wilms added a comment - ok. got answer via discord about this trouble. It is not in the stable branch yet. Thanks a lot.

          Ok. Can you explain me this?

          {{}}

          1. /opt/observium % svn update
            Updating '.':
            At revision 13018.
            # /opt/observium % ./
            [FFM - PROD] root@observium /opt/observium % ./discovery.php -u  ___   _                              _
             / _ \ | |__   ___   ___  _ __ __   _() _   _  _ __ ___
            {{| | | || '_ \ / _| / _ | '|\ \ / /| || | | || ' ` _ }}
            | || || |) |__ |  _/| |    \ V / | || || || | | | | |
             __/ |._/ |_/ _|||     _/  || _,||| || ||
                                      Observium Professional 23.9.13005
                                              https://www.observium.org-- Database is up to date.
            -- Observium is up to date.
            # /opt/observium % /etc/init.d/apache2 restart
            Restarting apache2 (via systemctl): apache2.service.



          It seems to be the right revision, but observing shows the wrong. So I mean I am in the last branch r13018{}



          twilms Torsten Wilms added a comment - Ok. Can you explain me this? {{}} /opt/observium % svn update Updating '.': At revision 13018. # /opt/observium % ./ [FFM - PROD] root@observium /opt/observium % ./discovery.php -u   ___   _                              _  / _ \ | |__   ___   ___  _ __ __   _ ( ) _   _  _ __ ___ {{| | | || '_ \ / _ | / _ | ' |\ \ / /| || | | || ' ` _ }} | | | || | ) |__ |  _ /| |    \ V / | || | | || | | | | |  __ / | ._ / | _ / _ || |     _/  | | _ , || | | | | |                           Observium Professional 23.9.13005                                   https://www.observium.org -- Database is up to date. -- Observium is up to date. # /opt/observium % /etc/init.d/apache2 restart Restarting apache2 (via systemctl): apache2.service.   It seems to be the right revision, but observing shows the wrong. So I mean I am in the last branch r 13018 { }

          show screenshot of your about page.

          landy Mike Stupalov added a comment - show screenshot of your about page.

          Please, can you reopen this issue?

          twilms Torsten Wilms added a comment - Please, can you reopen this issue?

          Sorry, but we using 13018. it is not fixed

          twilms Torsten Wilms added a comment - Sorry, but we using 13018. it is not fixed

          Should be fixed in r13018.

          landy Mike Stupalov added a comment - Should be fixed in r13018.

          /opt/observium/rrd/10.242.0.9/munin_ping_10.242.0.10_ping.rrd

          twilms Torsten Wilms added a comment - /opt/observium/rrd/10.242.0.9/munin_ping_10.242.0.10_ping.rrd

          General questions and device support can be discussed in our Discord channel, click here to join.


          Please make and attach additional information about the device:

          • full snmp dump from device:

            snmpwalk -v2c -c <community> -t 3 -Cc --hexOutputLength=0 -Ih -ObentxU <hostname> .1 > myagent.snmpwalk
            snmpwalk -v2c -c <community> -t 3 -Cc --hexOutputLength=0 -Ih -ObentxU <hostname> .1.3.6.1.4.1 >> myagent.snmpwalk

            If device not support SNMP version 2c, replace -v2c with -v1.

          • If you have problems with discovery or poller processes, please do and attach these debugs:

            ./discovery.php -d -h <device>
            ./poller.php -d -h <device>

          • additionally attach device and/or vendor specific MIB files

          This comment is added automatically.

          bot Observium Bot added a comment - General questions and device support can be discussed in our Discord channel, click here to join . Please make and attach additional information about the device: full snmp dump from device: snmpwalk -v2c -c <community> -t 3 -Cc --hexOutputLength=0 -Ih -ObentxU <hostname> .1 > myagent.snmpwalk snmpwalk -v2c -c <community> -t 3 -Cc --hexOutputLength=0 -Ih -ObentxU <hostname> .1.3.6.1.4.1 >> myagent.snmpwalk If device not support SNMP version 2c, replace -v2c with -v1. If you have problems with discovery or poller processes, please do and attach these debugs: ./discovery.php -d -h <device> ./poller.php -d -h <device> additionally attach device and/or vendor specific MIB files This comment is added automatically.
