Moxa EDS-P506E support.

Mike Stupalov added a comment - 2020/03/01 09:35 PM Updated in r10307.

Torstein Eide added a comment - 2020/02/18 02:50 PM I have 2 different models, on both i have the option to change the sysDescr.  So i wound assume that all moxa switche have user defined sysDescr. The test was on a " Moxa EDS-P506E-4PoE-2GTXSFP" .

Mike Stupalov added a comment - 2020/02/18 02:33 PM This is not recommended (and undocumented) way. Really all definitions MUST have real oid_num. You can use first discovery for translate, but fill correct numeric oids after.

Mike Stupalov added a comment - 2020/02/18 02:25 PM Hrm, and which hardware on this device?.. Ok, will change this regexp to match only EDS-* hardware.

Torstein Eide added a comment - 2020/02/17 04:33 PM The $config[ 'mibs' ][$mib][ 'processor' ][ 'swMgmt' ] "swMgmt" is the parent oid. okay, the oid and key can be the same.

Torstein Eide added a comment - 2020/02/17 04:24 PM Why? the discovery will translate it. i currently don't see the benefit of using my time on doing a task that the discovery script does more effectively at minimal cost.

Torstein Eide added a comment - 2020/02/17 04:10 PM Module Start: os #####   +-------------+-------------------------+ | OID | | +-------------+-------------------------+ | sysDescr | SW01 i PS102 | | sysObjectID | . 1.3 . 6.1 . 4.1 . 8691.7 . 162 | +-------------+-------------------------+   o Detect OS matched (moxa- switch : Moxa Switch): +-------------+---------------------+-------------------------+ | OID | Matched definition | | +-------------+---------------------+-------------------------+ | sysObjectID | . 1.3 . 6.1 . 4.1 . 8691.7 | . 1.3 . 6.1 . 4.1 . 8691.7 . 162 | +-------------+---------------------+-------------------------+     o Duration 0 .0701s   User defined. and with that we need a model.php entry per model anyway, it is redundant.

Torstein Eide added a comment - 2020/02/17 04:08 PM we do have OID that is definited.

Mike Stupalov added a comment - 2020/02/17 03:56 PM Please show why incorrect (examples of incorrect sysDescr) for hardware detect: -$config['os'][$os]['sysDescr_regex'][] = '/^(?:MOXA )?(?<hardware>\w\S+)/';

Mike Stupalov added a comment - 2020/02/17 03:52 PM and please still use file attachments.
