Cisco ASR1006 BGP peer monitoring issue

Details

    • Bug
    • Resolution: Not A Bug
    • Minor
    • None
    • Professional Edition
    • Poller
    • hardware, software

    Description

      Recently i have added ASR1006 Cisco router (eBGP) but in Routing tab i am not seeing any eBGP graph or stats, Do i need to do special config to monitor BGP peers?

      See following screenshot

      Attachments

        Activity

          [OBS-1895] Cisco ASR1006 BGP peer monitoring issue
          landy Mike Stupalov made changes -
          Status Original: Resolved [ 5 ] New: Closed [ 6 ]
          landy Mike Stupalov made changes -
          Resolution New: Not A Bug [ 6 ]
          Status Original: Open [ 1 ] New: Resolved [ 5 ]
          mtivi Martyushev Tim added a comment -



          By the way what is Ports > Peering

          http://docs.observium.org/port_descr_parsing/



          mtivi Martyushev Tim added a comment -   By the way what is Ports > Peering http://docs.observium.org/port_descr_parsing/
          satish.lx Satish Patel added a comment -

          By the way what is Ports > Peering

          Should i suppose to see something there?

          satish.lx Satish Patel added a comment - By the way what is Ports > Peering Should i suppose to see something there?
          satish.lx Satish Patel added a comment -

          Crap!!! BGP collection was disabled in Global setting

          Its working now! I can see BGP stats now.

          satish.lx Satish Patel added a comment - Crap!!! BGP collection was disabled in Global setting Its working now! I can see BGP stats now.
          satish.lx Satish Patel added a comment -

          We have BGP in main routing table, VRF is just for Management Interface. Find attached debug file debug.txt

          satish.lx Satish Patel added a comment - We have BGP in main routing table, VRF is just for Management Interface. Find attached debug file debug.txt
          satish.lx Satish Patel made changes -
          Attachment New: debug.txt [ 13242 ]
          landy Mike Stupalov added a comment -

          BGP table/instance in VRF or in main routing instance?

          Attach debug output for discovery:

          ./discovery.php -d -m bgp-peers -h <device>

          landy Mike Stupalov added a comment - BGP table/instance in VRF or in main routing instance? Attach debug output for discovery: ./discovery.php -d -m bgp-peers -h <device>
          satish.lx Satish Patel made changes -
          Attachment New: Screen Shot 2016-06-20 at 9.59.46 AM.png [ 13235 ]
          satish.lx Satish Patel made changes -
          Attachment Original: Screen Shot 2016-06-20 at 9.57.51 AM.png [ 13232 ]
